Hardware

Physical Port

1 × 10/100/1000Mbps WAN
2 × 10/100/1000Mbps LAN

Power Consumption

<10 W

Memory

128 MB Flash and 128 MB RAM

Indicator Light

1 × WPS

1 × 5GHz, 1 x 2.4GHz

1 × LAN

1 × Internet

1 × PWR

Button

1 × Reset/WPS button

Wireless Standard

2.4 GHz: 802.11 b/g/n
5 GHz: 802.11 a/n/a/ac/ax

Performance

Operating Frequency

2.412 GHz–2.484 GHz
5.150 GHz–5.850 GHz

Wireless Transmission Rate

2.4 GHz: 300 Mbps
5 GHz: 1201 Mbps

Channel Width

20/40/80 MHz

Max. Output Power

CE EIRP:

≤20 dBm@2400-2483.5 MHz

≤23 dBm@5150-5250 MHz

≤23 dBm@5250-5350 MHz

≤27 dBm@5470-5725 MHz

≤14 dBm@5725-5850 MHz

Antenna Gain

2.4 GHz: 5dBi (±0.5)
5 GHz: 5dBi (±0.5)

Receiver Sensitivity

2.4 GHz
11n HT20_MCS0: -95 dbm
11n HT20_MCS7: -75 dbm
11n HT40_MCS0: -92 dbm
11n HT40_MCS7: -72 dbm
5 GHz
11ac VHT80_MCS0: -89 dbm
11ac VHT80_MCS9: -62 dbm
11ax HE80_MCS0: -89 dbm
11ax HE80_MCS11: -59 dbm

Channel

2.4 GHz: 1-13
5 GHz: 36/40/44/48,52/56/60/64,149/151/153/157/161/165

Connected Wireless Terminals

2.4 GHz: 16
5 GHz: 32

Function

Encryption Mode

WPA-PSK
WPA2-PSK
WPA3-AES
WPA/WPA2-PSK
WPA2-PSK/WPA3-AES

Management and Log

NTP; Syslog

Firmware Update

Web/WiLynk App update

OFDMA

Yes

MU-MIMO

2 × 2

DHCP

Yes

NAT

Mapping based on port

QoS

Yes

DDNS

Yes

Parental Controls

Yes

Equipment Management

Web/WiLynk App

General

Power Supply

12 VDC,1 A

Operating Temperature

0 °C to 40 °C (32 °F to 104 °F)

Storage Temperature

–20 °C to +70 °C (–4 °F to 158 °F)

Operating Humidity

10%–90% (RH), non-condensing

Gross Weight

0.56 kg (1.23 lb)

Net Weight

0.26 kg (0.57 lb)

Packaging Dimensions

321 mm × 257 mm × 76 mm(12.63" × 10.11" × 2.99")(L × W × H)

Product Dimensions

215 mm × 119 mm × 173 mm (8.46" × 4.67" × 6.81")(L × W × H)

Statics Protection

Air discharge: 8 kV
Contact discharge: 4 kV

Lighting Protection

Common mode: 2.5 kV
Differential mode: 0.5 kV

Installation

Desktop mount

Packing List

1 × Device

1 × Power Adapter

1 × Network Cable

1 × Quick Start Guide

1 × Legal and Regulatory Information

1 × Frequency Band Information

1 × Warranty Card

1 × Product Information QR Code
